Xerox WorkCentre 6605 Service Manual

Maintenance
Xerox Internal Use Only Phaser 6600 and WorkCentre 6605
Service Manual
6-23
Adjusting the Fuser
The Fuser uses heat and pressure to bond the toner image to the paper. For optimal print quality, the
printer automatically adjusts the temperature of the Fuser when you change the paper type. Because
of differences in paper construction and thickness, the adjustment made by the printer is not enough
or is too much for all paper types. If the Fuser temperature is too low, the toner will not properly bond
to the paper. If the Fuser is too hot, the paper can curl.
Changing the Fuser temperature for a particular paper type requires entering Service Mode and editing
NVM using a specific Chain-Link code. Refer to “NVM Read and Write (Edit NVM)” on page 2-28 for
detailed instructions on editing NVM values.
To adjust the Fuser:
1. Identify the paper type for which you need to adjust the fuser temperature.
2. Enter Service Mode and navigate to Printer Diag > Engine Diag > NVM Settings > Edit NVM.
3. Enter the Chain-Link code for the paper identified in step 1. Refer to the table for the appropriate
Chain-Link code.
4. Adjust the value up or down as necessary, using one of the following settings:
-9, -6, -3, 0 (default), +3, +6, +9.
The value of the setting raises (if positive) or lowers (if negative) the Fuser temperature by that
many degrees celsius above or below the default temperature for the specified paper type and
printer speed. For example, entering +3 will raise the temperature by 3° C.
Media Name Media Mode Chain-Link Default
Plain Plain-H 744 016 0
Special Heavier - L 744 017 0
Hole Punched Plain-L 744 018 0
Colored Plain-L 744 019 0
Lightweight Cardstock Heavier-L 744 036 0
Heavyweight Cardstock Heavier-H 744 037 0
Labels Label-H 744 039 0
Envelope Envelope 744 041 0
Lightweight Glossy
Cardstock
Coated-M 744 044 0
Heavyweight Glossy
Cardstock
Coated-H 744 045 0
