Xerox WorkCentre 6605 Service Manual

Error Troubleshooting
Xerox Internal Use Only Phaser 6600 and WorkCentre 6605
Service Manual
2-225
Other Fault Isolation Procedures
Abnormal Noise
FIP-N1 Abnormal Noise: When Power is Turned On
Step Check Yes No
Possible causative parts:
•Toner Cartridge (Y, M, C, K) (PL5.1.8?PL5.1.11)
• Dispenser Motor (Y,M,C,K) [Upper Dispenser Motor
Assembly] (PL5.1.1)
• Main Motor [Drive Assembly] (PL3.1.1)
1 Check the Dispense Motor operation
Execute Digital Output diagnostic test 093-004(Y), 093-
006(M), 093-008(C), and 093-010(K), and check the
Dispenser Motor rotation.
Is the device making an abnormal noise?
CAUTION: Stop the Motor operation within 3
seconds, or the device will be damaged.
Go to step 2. Go to step 3.
2 Check the Toner Cartridge installation
Reinstall the Toner Cartridge.
Turn the power off, and then on again. Is the device making
an abnormal noise?
Replace the
Toner Cartridge.
If the trouble still
exists, replace
the device.
Finished.
3 Check the Main Motor operation
Execute Digital Output diagnostic test 071-001, and check
the Main Motor rotation.
Is the device making an abnormal noise?
CAUTION: Stop the Motor operation within 3
seconds, or the device will be damaged.
Replace the Main
Motor [Drive
Assembly].
Finished.

Xerox WorkCentre 6605 Specifications

General

Functions	Print, Copy, Scan, Fax
Print Technology	Laser
Print Resolution	Up to 600 x 600 x 4 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Fax Speed	33.6 Kbps
Standard Paper Capacity	550 sheets
Maximum Paper Capacity	1, 250 sheets
Paper Output	250 sheets
Duplex Printing	Yes
Processor	533 MHz
Memory (Standard)	512 MB
Memory (Maximum)	1 GB
Monthly Duty Cycle	Up to 80, 000 pages
Type	Multifunction
Copy Speed	Up to 36 cpm black and color
Fax Resolution	300 x 300 dpi
Media Sizes	Letter, Legal, A4, A5, B5, Custom sizes
Connectivity	USB 2.0, Ethernet
Mobile Printing	Apple AirPrint
Operating System Compatibility	Windows, Mac, Linux
Dimensions (W x D x H)	500 mm
Weight	29.6 kg
Print Speed	Up to 36 ppm (Black) / Up to 36 ppm (Color)
