Xerox WorkCentre 6605

General Information
Phaser 6600 and WorkCentre 6605 Xerox Internal Use Only
Service Manual
1-20
Parts of the Printer
Phaser 6600 Front View
Phaser 6600 Rear View
1. Tray 2 (Optional) 4. Control Panel
2. Tray 1 5. Right Side Door
3. Bypas Tray 6. Power Switch
1. Duplex Unit 6. IP Board
2. Transfer Roller 7. Left Side Door
3. Fuser 8. Ethernet Connection
4. Power Connector 9. Wireless Network Adapter Port
5. Rear Cover 10. USB Port
1
2
3
4
5
6
1
2
3
4
5
6
7
8
9
10
