Xerox WorkCentre 6605

General Information
Xerox Internal Use Only Phaser 6600 and WorkCentre 6605
Service Manual
1-49
UI (User Interface) and MFP Engine
MFP Control Panel (PL1.1.1)
The MFP Console Assembly displays the state of the printer and fax using LCD and LED, and
operates the printer and fax using the buttons.
FAX Board (PL18.1.41) controls the FAX signal.
s6600-216
FAX Board
MFP Control Panel
