Xerox WorkCentre 6605 Service Manual

Wiring
Xerox Internal Use Only Phaser 6600 and WorkCentre 6605
Service Manual
7-43
HVPS
Development HVPS
Board
PL18.1.14
Transfer Roller
BCR (Y)
Deve (Color)
BCR (M)
BCR (C)
1st BTR (Y)
1st BTR (M)
1st BTR (C)
1st BTR (K)
Transfer Roller
Drum Y
Drum M
Drum C
Drum K
MCU Board
PL18.1.13
P/J182
1
2
I-MONITOR TR2
3
4
DA TR2
DA TR2 CLN
5
DA TR1 K
6
7
+3V REF
8
9
10
CLOCK1
I/L +24VDC
11
P/J1821
11
10
9
8
7
6
5
4
3
2
1
RTN
Transfer HVPS
Board
PL18.1.28
P/J18
1
2
DA DO
CLOCK 1
3
4
DA DI
I MONITER
5
+3VREF
6
7
CLOCK 2
8
9
10
CLOCK 3
I/L +24VDC
RTN
11
12
P/J181
1
2
3
4
5
6
7
8
9
10
11
12
DA CLOCK
DA LD
I/L +24VDC
RTN
I/L +24VDC
13 13
SG
+3VDC
DA TR1 CLR
CLOCK3
BCR (K)
Deve (K)
HVPS Harness Assembly
PL18.2.6
MCU-HVPS Flat Flex Cable
PL18.2.7
s6600-228

Xerox WorkCentre 6605 Specifications

General

Functions	Print, Copy, Scan, Fax
Print Technology	Laser
Print Resolution	Up to 600 x 600 x 4 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Fax Speed	33.6 Kbps
Standard Paper Capacity	550 sheets
Maximum Paper Capacity	1, 250 sheets
Paper Output	250 sheets
Duplex Printing	Yes
Processor	533 MHz
Memory (Standard)	512 MB
Memory (Maximum)	1 GB
Monthly Duty Cycle	Up to 80, 000 pages
Type	Multifunction
Copy Speed	Up to 36 cpm black and color
Fax Resolution	300 x 300 dpi
Media Sizes	Letter, Legal, A4, A5, B5, Custom sizes
Connectivity	USB 2.0, Ethernet
Mobile Printing	Apple AirPrint
Operating System Compatibility	Windows, Mac, Linux
Dimensions (W x D x H)	500 mm
Weight	29.6 kg
Print Speed	Up to 36 ppm (Black) / Up to 36 ppm (Color)
