Xerox WorkCentre 6605 Service Manual

Image Quality
Xerox Internal Use Only Phaser 6600 and WorkCentre 6605
Service Manual
3-3
Image Quality Troubleshooting Chart
When an image quality problem occurs during printing, output a sample print to determine and grasp
the nature of the problem, then use the list of problem descriptions on page 3-4 to select a
troubleshooting procedure from the Image Quality FIP.
If the problem persists even after the troubleshooting with the Image Quality FIP, check using the
Image Quality FIP again, and then replace the "Possible causative parts" listed in the Image Quality
FIP one by one, and also troubleshoot using the procedures in Chapter 2, Error Troubleshooting.
Start
No
Yes
Test Prin t ing
Carry out the corresponding troubleshooting.
End
The trouble is restored?
Is there a corresponding FIP?
No
Yes
Remove Toner Cartridge, shake it several
times, and reinstall it.
End
The trouble is restored?
Yes
No
Replace Toner Cartridge, Imaging
Unit, Transfer Belt, and Fuser
Assembly one by one.

Xerox WorkCentre 6605 Specifications

General

Functions	Print, Copy, Scan, Fax
Print Technology	Laser
Print Resolution	Up to 600 x 600 x 4 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Fax Speed	33.6 Kbps
Standard Paper Capacity	550 sheets
Maximum Paper Capacity	1, 250 sheets
Paper Output	250 sheets
Duplex Printing	Yes
Processor	533 MHz
Memory (Standard)	512 MB
Memory (Maximum)	1 GB
Monthly Duty Cycle	Up to 80, 000 pages
Type	Multifunction
Copy Speed	Up to 36 cpm black and color
Fax Resolution	300 x 300 dpi
Media Sizes	Letter, Legal, A4, A5, B5, Custom sizes
Connectivity	USB 2.0, Ethernet
Mobile Printing	Apple AirPrint
Operating System Compatibility	Windows, Mac, Linux
Dimensions (W x D x H)	500 mm
Weight	29.6 kg
Print Speed	Up to 36 ppm (Black) / Up to 36 ppm (Color)
