Xerox WorkCentre 6605 Service Manual

Wiring
Xerox Internal Use Only Phaser 6600 and WorkCentre 6605
Service Manual
7-11
WorkCentre 6605 Plug/Jack Designators
P/J Coordiates Remarks
1 G-183 Not Connects
10 H-164 Connects MCU Board and Main Harness Assembly
11 I-165 Connects MCU Board and Laser Unit
12 J-163 Connects MCU Board and X CRUM Harness Assembly
13 I-164 Connects MCU Board and Regi Harness Assembly
14 H-163 Connects MCU Board and Upper Dispenser Motor Assembly
15 I-163 Connects MCU Board and Sensor Harness Assembly
17 H-163 Connects MCU Board and Drive Harness Assembly
18 H-165 Connects MCU Board and MCU-HVPS Flat Flex Connector (FFC)
19 J-163 Connects MCU Board and Top Harness Assembly
21 H-164 Connects MCU Board and Bypass Tray Harness Assembly
22 H-164 Connects MCU Board and Duplex Clutch
23 H-164 Connects MCU Board and Regi Harness Assembly
27 J-165 Connects MCU Board and Main Harness Assembly
28 J-164 Connects MCU Board and Fuser Harness Assembly
29 J-164 Connects MCU Board and Top Harness Assembly
30 H-163 Connects MCU Board and Top Harness Assembly
33 H-164 Connects MCU Board and Drive Harness Assembly
36 I-165 Connects MCU Board and Laser Unit
38 J-163 Connects MCU Board and Exit Clutch2 [Exit Drive Assembly]
39 J-164 Connects MCU Board and Regi Harness Assembly
40 B-158 Connects LVPS and Top Harness Assembly
40 J-163 Connects MCU Board and Exit Clutch1 [Exit Drive Assembly]
41 B-157 Connects LVPS and Rear Interlock Switch
42 B-157 Connects LVPS and Front Interlock Switch
43 B-158 Connects LVPS and Top Harness Assembly
47 H-157 Connects LVPS and Heater Harness Assembly
48 H-158 Connects LVPS and SW Harness Assembly
101 D-163 Connects IP Board and Main Harness Assembly

Xerox WorkCentre 6605 Specifications

General

Functions	Print, Copy, Scan, Fax
Print Technology	Laser
Print Resolution	Up to 600 x 600 x 4 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Fax Speed	33.6 Kbps
Standard Paper Capacity	550 sheets
Maximum Paper Capacity	1, 250 sheets
Paper Output	250 sheets
Duplex Printing	Yes
Processor	533 MHz
Memory (Standard)	512 MB
Memory (Maximum)	1 GB
Monthly Duty Cycle	Up to 80, 000 pages
Type	Multifunction
Copy Speed	Up to 36 cpm black and color
Fax Resolution	300 x 300 dpi
Media Sizes	Letter, Legal, A4, A5, B5, Custom sizes
Connectivity	USB 2.0, Ethernet
Mobile Printing	Apple AirPrint
Operating System Compatibility	Windows, Mac, Linux
Dimensions (W x D x H)	500 mm
Weight	29.6 kg
Print Speed	Up to 36 ppm (Black) / Up to 36 ppm (Color)
