Xerox WorkCentre 6605

General Information
Xerox Internal Use Only Phaser 6600 and WorkCentre 6605
Service Manual
1-21
Phaser 6600 Internal Parts
WorkCentre 6605 Front View
1. Front Cover 4. Imaging Unit
2. Toner Cartridges 5. Waste Cartridge
3. Transfer Belt
1. Tray 1 6. Duplex Automatic Document Feeder
2. Bypass Tray 7. Output Tray
3. Front Door 8. Right Side Door
4. USB Memory Port 9. Power Switch
5. Control Panel 10. Tray 2, Optional 550-Sheet Feeder
1
2
3
5
4
1
3
5
6
7
8
9
10
4
2
