Xerox WorkCentre 6605

General Information
Phaser 6600 and WorkCentre 6605 Xerox Internal Use Only
Service Manual
1-22
WorkCentre 6605 Rear and Side Views
1. Duplex Unit 8. Ethernet Connection
2. Transfer Roller 9. USB Port
3. Fuser 10. Wireless Network Adapter Port
4. Power Connector 11. Phone Connector
5. Rear Door 12. Fax Line Connector
6. IP Board 13. Phone Line Cover
7. Left Side Door
6
7
9
8
10
11
1213
1
2
3
4
5
