Xerox WorkCentre 6605 Service Manual

Wiring
Xerox Internal Use Only Phaser 6600 and WorkCentre 6605
Service Manual
7-31
Signal line name Description
REAR IL ON/OFF detect signal of the Rear Interlock Switch
DOOR IL ON/OFF detect signal of the Door Interlock Switch
FAN ALRM
FAN LOW
FAN STOP
Drive control signal of the Main Fan
WASTE BOX FULL SENSED SIGNAL Full detect signal of the Waste Cartridge by the Toner Full Sensor

Xerox WorkCentre 6605 Specifications

General

Functions	Print, Copy, Scan, Fax
Print Technology	Laser
Print Resolution	Up to 600 x 600 x 4 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Fax Speed	33.6 Kbps
Standard Paper Capacity	550 sheets
Maximum Paper Capacity	1, 250 sheets
Paper Output	250 sheets
Duplex Printing	Yes
Processor	533 MHz
Memory (Standard)	512 MB
Memory (Maximum)	1 GB
Monthly Duty Cycle	Up to 80, 000 pages
Type	Multifunction
Copy Speed	Up to 36 cpm black and color
Fax Resolution	300 x 300 dpi
Media Sizes	Letter, Legal, A4, A5, B5, Custom sizes
Connectivity	USB 2.0, Ethernet
Mobile Printing	Apple AirPrint
Operating System Compatibility	Windows, Mac, Linux
Dimensions (W x D x H)	500 mm
Weight	29.6 kg
Print Speed	Up to 36 ppm (Black) / Up to 36 ppm (Color)
