Xerox WorkCentre 6605 Service Manual

Wiring
Xerox Internal Use Only Phaser 6600 and WorkCentre 6605
Service Manual
7-25
9 Xerographic Connections of XERO DEVE CRU Assembly Y with MCU Board.
Connections of XERO DEVE CRU Assembly M with MCU Board.
Connections of XERO DEVE CRU Assembly C with MCU Board.
Connections of XERO DEVE CRU Assembly K with MCU Board.
Connections of CTD Sensor with MCU Board.
Connections of PWBA EEPROM with MCU Board.
10 Developer Connections of TONER CARTRIDGE Y with MCU Board.
Connections of TONER CARTRIDGE M with MCU Board.
Connections of TONER CARTRIDGE C with MCU Board.
Connections of TONER CARTRIDGE K with MCU Board.
Connections of Toner Dispense Motor(Y,M) with MCU Board.
Connections of Toner Dispense Motor(C,K) with MCU Board.
Connections of Front Cover Sensor with MCU Board.
11 Exit Connections of Exit Sensor with MCU Board.
Connections of Full Stack Sensor with MCU Board.
Connections of Exit Clutch 1 with MCU Board.
Connections of Exit Clutch 2 with MCU Board.
12 550 Feeder Connections of 550 Option Feeder Board with MCU Board.
Connections of Tum Roll Clutch with 550 Option Feeder Board.
Connections of CHUTE Assembly PINCH 550 with 550 Option
Feeder Board.
Connections of Feed Clutch with 550 Option Feeder Board.
Connections of 550 Size Switch Assembly with 550 Option
Feeder Board.
Connections of DRIVE Assembly OPT 550 with 550 Option
Feeder Board.
13 Scanner Connections of Scanner Assembly with IP Board.
Connections of Scanner Assembly with Control Panel Assembly.
Diagram Connection Details

Xerox WorkCentre 6605 Specifications

General

Functions	Print, Copy, Scan, Fax
Print Technology	Laser
Print Resolution	Up to 600 x 600 x 4 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Fax Speed	33.6 Kbps
Standard Paper Capacity	550 sheets
Maximum Paper Capacity	1, 250 sheets
Paper Output	250 sheets
Duplex Printing	Yes
Processor	533 MHz
Memory (Standard)	512 MB
Memory (Maximum)	1 GB
Monthly Duty Cycle	Up to 80, 000 pages
Type	Multifunction
Copy Speed	Up to 36 cpm black and color
Fax Resolution	300 x 300 dpi
Media Sizes	Letter, Legal, A4, A5, B5, Custom sizes
Connectivity	USB 2.0, Ethernet
Mobile Printing	Apple AirPrint
Operating System Compatibility	Windows, Mac, Linux
Dimensions (W x D x H)	500 mm
Weight	29.6 kg
Print Speed	Up to 36 ppm (Black) / Up to 36 ppm (Color)
