Wiring
Xerox Internal Use Only Phaser 6600 and WorkCentre 6605
Service Manual
7-23
Denotes an On-Off Switch (single-pole, single-
throw switch).
Denotes an On-Off Switch (Temperature -
normally close).
Denotes an NPN Photo-transistor.
I/L +24 VDC Denotes DC voltage when the Interlock
Switch in MCU Board turns On.
+5 VDC
+3.3 VDC
Denotes DC voltage.
SG Denotes signal ground.
AG Denotes analog ground.
RTN Denotes return.
Symbol Description
To Next Page
