Xerox WorkCentre 6605 Service Manual

Error Troubleshooting
Phaser 6600 and WorkCentre 6605 Xerox Internal Use Only
Service Manual
2-208
005-110 Pickup Jam
005-121 ADF Jam
005-124 Virtual Jam
4 Check after replacing the Black Imaging Unit
Replace the Black Imaging Unit.
Does the error still occur?
Replace the MCU
Board.
Finished.
Step Check Yes No
Possible causative parts:
• DADF Assembly (PL51.1.2)
• IIT Pick-up Module Kit (PL51.1.4)
• IP Board (PL18.1.22)
1 Check the document
Does the document meet the specifications of the printer?
Go to step 2. Use the right
document.
2 Check the DADF Assembly
Is the DADF Assembly closed properly against the platen
glass?
Go to step 3. Close the DADF
Assembly
properly.
3 Check the DADF Assembly connection
Check the connection between the DADF Assembly and the
IP Board.
Is P/J1502 connected securely?
Go to step 4. Connect P/J1502
securely.
4 Check the document path
Open the DADF cover and check the document path.
Are there any foreign objects, or paper pieces, etc. on the
document path?
Remove the
foreign objects,
or paper pieces,
etc.
Go to step 5.
5 Check the IIT Pick-up Module Kit
Is the IIT Pick-up Module Kit installed properly?
Go to step 3. Reinstall the IIT
Pick-up Module
Kit.
6 Check the IIT Pick-up Module Kit
Is the IIT Pick-up Module Kit deformed or worn out?
Replace the KIT
IIT Pick-up
Module.
Go to step 7.
7 Check after replacing the DADF Assembly
Replace the DADF Assembly.
Does the error still occur?
Replace the IP
Board.
Finished.
Step Check Yes No

Xerox WorkCentre 6605 Specifications

General

Functions	Print, Copy, Scan, Fax
Print Technology	Laser
Print Resolution	Up to 600 x 600 x 4 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Fax Speed	33.6 Kbps
Standard Paper Capacity	550 sheets
Maximum Paper Capacity	1, 250 sheets
Paper Output	250 sheets
Duplex Printing	Yes
Processor	533 MHz
Memory (Standard)	512 MB
Memory (Maximum)	1 GB
Monthly Duty Cycle	Up to 80, 000 pages
Type	Multifunction
Copy Speed	Up to 36 cpm black and color
Fax Resolution	300 x 300 dpi
Media Sizes	Letter, Legal, A4, A5, B5, Custom sizes
Connectivity	USB 2.0, Ethernet
Mobile Printing	Apple AirPrint
Operating System Compatibility	Windows, Mac, Linux
Dimensions (W x D x H)	500 mm
Weight	29.6 kg
Print Speed	Up to 36 ppm (Black) / Up to 36 ppm (Color)
