Xerox WorkCentre 6605 Service Manual

Error Troubleshooting
Xerox Internal Use Only Phaser 6600 and WorkCentre 6605
Service Manual
2-207
092-672 Cyan Patch Error
092-673 Black Patch Error
Step Check Yes No
Possible causative parts:
• Cyan Imaging Unit (PL8.1.4)
• Cyan Toner Cartridge (PL5.1.10)
• MCU Board (PL18.1.13)
1 Check after reinstalling the Toner Cartridge
Pull out and shake the Cyan Toner Cartridge, and then
reinstall it.
Does the error still occur?
Go to step 2. Finished.
2 Check after replacing the Toner Cartridge
Replace the Cyan Toner Cartridge.
Does the error still occur?
Go to step 3. Finished.
3 Check the Imaging Unit installation
Take out the Cyan Imaging Unit.
Is the connection part of the Cyan Imaging Unit clean? And,
is the Cyan Imaging Unit touching against the guides on the
left and right sides, and installed properly?
Go to step 4. Clean the
connection part.
Reinstall the
Cyan Imaging
Unit.
4 Check after replacing the Cyan Imaging Unit
Replace the Cyan Imaging Unit.
Does the error still occur?
Replace the MCU
Board.
Finished.
Step Check Yes No
Possible causative parts:
• Black Imaging Unit (PL8.1.5)
• Black Toner Cartridge (PL5.1.11)
• MCU Board (PL18.1.13)
1 Check after reinstalling the Toner Cartridge
Pull out and shake the Black Toner Cartridge, and then
reinstall it.
Does the error still occur?
Go to step 2. Finished.
2 Check after replacing the Toner Cartridge
Replace the Black Toner Cartridge.
Does the error still occur?
Go to step 3. Finished.
3 Check the Imaging Unit installation
Take out the Black Imaging Unit.
Is the connection part of the Black Imaging Unit clean? And,
is the Black Imaging Unit touching against the guides on the
left and right sides, and installed properly?
Go to step 4. Clean the
contact point.
Reinstall the
Black Imaging
Unit.

Xerox WorkCentre 6605 Specifications

General

Functions	Print, Copy, Scan, Fax
Print Technology	Laser
Print Resolution	Up to 600 x 600 x 4 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Fax Speed	33.6 Kbps
Standard Paper Capacity	550 sheets
Maximum Paper Capacity	1, 250 sheets
Paper Output	250 sheets
Duplex Printing	Yes
Processor	533 MHz
Memory (Standard)	512 MB
Memory (Maximum)	1 GB
Monthly Duty Cycle	Up to 80, 000 pages
Type	Multifunction
Copy Speed	Up to 36 cpm black and color
Fax Resolution	300 x 300 dpi
Media Sizes	Letter, Legal, A4, A5, B5, Custom sizes
Connectivity	USB 2.0, Ethernet
Mobile Printing	Apple AirPrint
Operating System Compatibility	Windows, Mac, Linux
Dimensions (W x D x H)	500 mm
Weight	29.6 kg
Print Speed	Up to 36 ppm (Black) / Up to 36 ppm (Color)
