Xerox WorkCentre 6605 Service Manual

Error Troubleshooting
Xerox Internal Use Only Phaser 6600 and WorkCentre 6605
Service Manual
2-223
+5 VDC Power FIP
Step Check Yes No
Possible causative parts:
• Top Harness Assembly (PL18.2.5)
• AC Inlet (PL18.1.31)
• LVPS (PL18.1.34)
• MCU Board (PL18.1.13)
1 Check the connections between LVPS and the MCU Board
Check the connection between the LVPS and the MCU Board.
Are P/J501 and P/J29 connected securely?
Go to step 2. Reconnect
P/J501 and P/J29
securely.
2 Check the continuity between the LVPS and the MCU Board
Is each cable of P/J501<=>P/J29 continuous?
Go to step 3. Replace the Top
Harness
Assembly.
3 Check the power from the LVPS (+5 VDC)
Check if the voltage between the LVPS ground and the
P/J501-3 pin is about +5 VDC.
Replace the MCU
Board.
Go to step 4.
4Check the power (off/on)
Turn the power off, wait a while, and turn the power on
again.
Does the error still occur?
Go to step 5. Finished.
5 Check the AC power to the LVPS
Is the voltage between the P/J48-1 pin and the P/J48-3 pin
of the LVPS 100 VAC?
Replace the LVPS. Replace the AC
Inlet.

Xerox WorkCentre 6605 Specifications

General

Functions	Print, Copy, Scan, Fax
Print Technology	Laser
Print Resolution	Up to 600 x 600 x 4 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Fax Speed	33.6 Kbps
Standard Paper Capacity	550 sheets
Maximum Paper Capacity	1, 250 sheets
Paper Output	250 sheets
Duplex Printing	Yes
Processor	533 MHz
Memory (Standard)	512 MB
Memory (Maximum)	1 GB
Monthly Duty Cycle	Up to 80, 000 pages
Type	Multifunction
Copy Speed	Up to 36 cpm black and color
Fax Resolution	300 x 300 dpi
Media Sizes	Letter, Legal, A4, A5, B5, Custom sizes
Connectivity	USB 2.0, Ethernet
Mobile Printing	Apple AirPrint
Operating System Compatibility	Windows, Mac, Linux
Dimensions (W x D x H)	500 mm
Weight	29.6 kg
Print Speed	Up to 36 ppm (Black) / Up to 36 ppm (Color)
