Xerox WorkCentre 6605

Parts Lists
Phaser 6600 and WorkCentre 6605 Xerox Internal Use Only
Service Manual
5-16
Parts List 4.1 NOHAD
Item Name Part Number
1Duct_frame_seg3 (Frame Duct) —
2 Duct_base_seg3 (Base Duct) —
3 Spring Latch (Latch Spring) —
4 Latch Rear R (Right Rear Latch) —
5 Bracket Latch L (Left Latch Bracket) —
6Frame Rear S3 —
7Actuator-Belt IL RT —
8Holder-Belt IL —
9Spring-Belt IL —
10 Actuator-Belt IL LN —
11 Cover-Sensor Waste (Waste Sensor Cover) —
12 Screw Fan —
13 Fan Main (Main Fan) 127E86480
14 — —
15 Foot Base Front (Front Base Foot) —
16 Foot —
17 Sensor Toner Full (Toner Full Sensor) 930W00511
18 Latch Rear L (Left Rear Latch) —
97 Kit Latch L (with3,18) (Left Latch Kit) 604K73980
98 Kit Foot Assy (with15x4,16x4) (Foot Assembly Kit) 604K76341
99 Kit Latch R (with3,4) (Right Latch Kit) 604K76350
