Xerox WorkCentre 6605

Parts Lists
Phaser 6600 and WorkCentre 6605 Xerox Internal Use Only
Service Manual
5-28
Parts List 10.1 Option Feeder
Item Name Part Number
1 Feeder Assy Opt 550 (with2-19,PL10.2) (Optional 550-
Sheet Feeder)
604K77500
2 Cover Side L 550 Opt (550 Option Left-Side Cover) —
3— —
4— —
5 Cover Side R 550 Opt (550 Option Right Side Cover) —
6 Stopper CST (Cassette Stopper) 803E10840
7 Foot Assembly —
8 Clutch Assy Opt Feed (550 Option Feed Clutch
Assembly)
005K83210
9 Drive Assy Opt 550 (550 Option Drive Assembly) 007K18020
10 PWBA Feed-H (550 Option Feeder Board) 960K62140
11 Switch Assy Size 550 (550 Size Switch Assembly) 110K16610
12 — —
13 Harness Assy Fdr Drawer1 (Drawer 1 Feeder Harness
Assembly)
—
14 Harness Assy C2 Size (C2 Size Harness Assembly) —
15 Harness Assy C2 Turn (C2 Turn Harness Assembly) —
16 Harness Assy Fdr Mot (Feeder Motor Harness Assembly) —
17 Screw Joint (Joint Screw) —
18 Foot Base Front —
19 Foot —
