Xerox WorkCentre 6605 Service Manual

Parts Lists
Xerox Internal Use Only Phaser 6600 and WorkCentre 6605
Service Manual
5-35
Parts List 13.2 Bypass Tray
Item Name Part Number
1 Frame Assy MSI (with2-26) (Bypass Tray Frame Assembly) 801K47622
2 Frame MSI (Bypass Tray Frame) —
3 Bracket No Paper MSI (Bypass Tray No Paper Bracket) —
4
MSI Detect Sensor (Bypass Tray No Paper Sensor
)
—
5 Harness Assy MSI (Bypass Tray Harness Assembly) —
6 Guide Harness MSI (Bypass Tray Harness Guide) —
7 Spring Feed —
8 Gear Feed MSI (Bypass Tray Feed Gear) —
9 Solenoid Feed MSI (Bypass Tray Feed Solenoid) —
10 Roll Assy Feed (Feed Roller Assembly) 059K78701
11 Cam MSI L (Left Bypass Tray Cam) —
12 Roll Core —
13 Holder Feed —
14 Shaft Feed MSI (Bypass Tray Feed Shaft) —
15 Cam MSI R (Right Bypass Tray Cam) —
16 Guide Support R (Right Support Guide) —
17 Guide Support L (Left Support Guide) —
18 Arm R (Right Arm) —
19 Spring NF (NF Spring) —
20 Arm L (Left Arm) —
21 Bracket Gear (Gear Bracket) —
22 Follower R (Right Follower) —
23 Follower L (Left Follower) —
24 Guide Bottom R (Right Bottom Guide) —
25 Slide Bottom (Bottom Slide) —
26 Guide Bottom L (Left Bottom Guide) —
98 Kit Roll Assy (with10-15) (Roller Kit Assembly) 604K73910
99 Kit Solenoid Assy (with7-9) (Solenoid Kit Assembly) 604K73921

Xerox WorkCentre 6605 Specifications

General

Functions	Print, Copy, Scan, Fax
Print Technology	Laser
Print Resolution	Up to 600 x 600 x 4 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Fax Speed	33.6 Kbps
Standard Paper Capacity	550 sheets
Maximum Paper Capacity	1, 250 sheets
Paper Output	250 sheets
Duplex Printing	Yes
Processor	533 MHz
Memory (Standard)	512 MB
Memory (Maximum)	1 GB
Monthly Duty Cycle	Up to 80, 000 pages
Type	Multifunction
Copy Speed	Up to 36 cpm black and color
Fax Resolution	300 x 300 dpi
Media Sizes	Letter, Legal, A4, A5, B5, Custom sizes
Connectivity	USB 2.0, Ethernet
Mobile Printing	Apple AirPrint
Operating System Compatibility	Windows, Mac, Linux
Dimensions (W x D x H)	500 mm
Weight	29.6 kg
Print Speed	Up to 36 ppm (Black) / Up to 36 ppm (Color)
