Xerox WorkCentre 6605

Parts Lists
Phaser 6600 and WorkCentre 6605 Xerox Internal Use Only
Service Manual
5-40
Parts List 15.1 Registration / Feeder
Item Name Part Number
1— —
2 Chute Dup Upper (Upper Duplex Chute) —
3 Chute Assy Dup Regi (Regi Duplex Chute Assembly) —
4 Chute Regi Lower —
5 Chute Regi Opt 550 —
6 Chute Assy Upper IBT (Upper Transfer Belt Chute Assembly) 054K46650
7— —
8 Clutch Assy Regi (Regi Clutch Assembly) —
9 Guide Tray L (Left Tray Guide) —
10 Stopper CST (Cassette Stopper) —
11 Gear Idle 28 —
12 Gear Idle 25 —
13 Cover Gear MSI —
14 Guide Tray R (Right Tray Guide) —
15 — —
98 Kit Chute Dup Assy (with2,3) (Duplex Chute Assembly Kit) 054K46640
99A Kit Chute Regi High Assy DN(with2-5,PL15.2) (Upper Regi
Chute Assembly Kit DN)
604K77750
99B Kit Chute Regi High Assy N(with2-5,PL15.2) (Upper Regi
Chute Assembly Kit N)
604K77760
