Xerox WorkCentre 6605

Parts Lists
Phaser 6600 and WorkCentre 6605 Xerox Internal Use Only
Service Manual
5-42
Parts List 15.2 Registration / Feeder
Item Name Part Number
1 Chute Assy Regi (with2-8) (Regi Chute Assembly) 054K47990
2 Bearing Regi R (Right Regi Bearing) —
3 Cover Dup Gear (Duplex Gear Cover) —
4Bearing CLH AD —
5 Clutch Assy Dup (Duplex Clutch Assembly) 121K48680
6 Clutch Assy Opt Feed (Feed Clutch Assembly) —
7 Roll Assy Feed (Feed Roller Assembly) —
8 Harness Assy Regi (Regi Harness Assembly) —
9 Chute Sub Assy Regi (Regi Chute Sub-Assembly) —
