Xerox WorkCentre 6605

Parts Lists
Phaser 6600 and WorkCentre 6605 Xerox Internal Use Only
Service Manual
5-44
Parts List 17.1 Exit
Item Name Part Number
1 Kit Assy Exit (with2-18,22) (Exit Kit Assembly) 054K49180
2Plate Earth Exit B —
3Plate Earth Exit A —
4Actuator Exit B —
5 Spring Actuator B —
6Actuator Exit A —
7 Spring Actuator A —
8Chute Exit Upper S3 —
9Eliminator Exit —
10 Actuator Full Stack —
11 Sensor-Photo Int (Interlock Photo Sensor) —
12 Chute Exit Lower S3 —
13 Bearing-Exit —
14 Roll Assy Exit (Exit Roller Assembly) —
15 Gear Exit —
16 Roll-Pinch —
17 Spring-Pinch —
18 Harness Assy Exit Snr (Exit Sensor Harness Assembly) —
19 — —
20 Cover Exit Tray (Exit Tray Cover) —
21A Drive Assy Exit DN (Exit Drive Assembly - DN) 007K18762
21B Drive Assy Exit N (Exit Drive Assembly - N) 007K18772
22 Flapper Exit —
23 Harness Assy Snr (Sensor Harness Assembly) —
