Xerox WorkCentre 6605 Service Manual

Wiring
Xerox Internal Use Only Phaser 6600 and WorkCentre 6605
Service Manual
7-5
509 B-158 Connects LVPS and Top Harness Assembly
1821 C-173 Connects Transfer HVPS and HVPS Harness Assembly
4201 E-184 Connects C2 Turn Clutch and C2 Turn Harness Assembly
4202 E-184 Connects No Paper Harness Assembly and C2 Turn Harness Assembly
4203 D-182 Connects C2 No Paper Sensor and No Paper Harness Assembly
4211 I-183 Connects CST Size Switch and C2 Size Harness Assembly
4212 D-182 Connects C2 Regi Sensor and Preregi Sensor Harness Assembly
4213 E-184 Connects C2 Feed Clutch and C2 Size Harness Assembly
4214 E-184 Connects Preregi Sensor Harness Assembly and C2 Size Harness Assembly
4221 F-183 Connects Option Feeder Motor and Feeder Motor Harness Assembly
281-S E-152 Connects Fuser and Fuser Harness Assembly
CN1 F-108 Connects Control Panel Assembly and Control Panel Harness
P/J Coordiates Remarks

Xerox WorkCentre 6605 Specifications

General

Functions	Print, Copy, Scan, Fax
Print Technology	Laser
Print Resolution	Up to 600 x 600 x 4 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Fax Speed	33.6 Kbps
Standard Paper Capacity	550 sheets
Maximum Paper Capacity	1, 250 sheets
Paper Output	250 sheets
Duplex Printing	Yes
Processor	533 MHz
Memory (Standard)	512 MB
Memory (Maximum)	1 GB
Monthly Duty Cycle	Up to 80, 000 pages
Type	Multifunction
Copy Speed	Up to 36 cpm black and color
Fax Resolution	300 x 300 dpi
Media Sizes	Letter, Legal, A4, A5, B5, Custom sizes
Connectivity	USB 2.0, Ethernet
Mobile Printing	Apple AirPrint
Operating System Compatibility	Windows, Mac, Linux
Dimensions (W x D x H)	500 mm
Weight	29.6 kg
Print Speed	Up to 36 ppm (Black) / Up to 36 ppm (Color)
