Xerox WorkCentre 6605

Wiring
Xerox Internal Use Only Phaser 6600 and WorkCentre 6605
Service Manual
7-41
Signal line name Description
LINE SYNC
PAGE SYNC Y
PAGE SYNC M
PAGE SYNC C
PAGE SYNC K
TEST PRINT
CMD READY
COMMAND
STATUS
RDY PWR ON
IOT PWR STS
Control signal of the PWBA ESS
DATA Y
xDATA Y
DATA M
xDATA M
DATA C
xDATA C
DATA K
xDATA K
Image data of each color (Y/M/C/K)
RXD
TXD
Control signal of the PANEL Assembly UI
