Xerox WorkCentre 6605

Wiring
Phaser 6600 and WorkCentre 6605 Xerox Internal Use Only
Service Manual
7-46
Signal line name Description
DATA
CLOCK
Control signal of the XERO DEVE CRU Assembly Y/M/C/K and the
PWBA EEPROM
CTD VOUT Toner patch density data measured by the CTD Sensor
LED ON LED lighting signal of the CTD Sensor
CTD VMONTOR Voltage monitor signal of the CTD Sensor
