Xerox WorkCentre 6605 Service Manual

Wiring
Phaser 6600 and WorkCentre 6605 Xerox Internal Use Only
Service Manual
7-50
Signal line name Description
FEED TRAY SENS
FEED RXD
FEED TXD
Control signal of the 550 Option Feeder Board
TURN ROLL CLUTCH ON ON/OFF signal of the Turn Roll Clutch
TRAY PAPER SENSED SIGNAL Detect signal of paper inside the optional tray by the C2 No
Paper Sensor
REGI PAPER SENSED SIGNAL Detect signal of paper in the Registration section of the optional
tray by the C2 Regi Sensor
FEED ROLL CLUTCH ON ON/OFF signal of the C2 Feed Clutch
SIZE3
SIZE2
SIZE1
Detect signal of a paper size inside the optional tray by the 550
Size Switch Assembly
OP FEED MOTOR ON
OP FEED MOTOR ALARM
OP FEED MOTOR CLOCK
OP FEED MOTOR GAIN
Drive control signal of the Option Feeder Motor

Xerox WorkCentre 6605 Specifications

General

Functions	Print, Copy, Scan, Fax
Print Technology	Laser
Print Resolution	Up to 600 x 600 x 4 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Fax Speed	33.6 Kbps
Standard Paper Capacity	550 sheets
Maximum Paper Capacity	1, 250 sheets
Paper Output	250 sheets
Duplex Printing	Yes
Processor	533 MHz
Memory (Standard)	512 MB
Memory (Maximum)	1 GB
Monthly Duty Cycle	Up to 80, 000 pages
Type	Multifunction
Copy Speed	Up to 36 cpm black and color
Fax Resolution	300 x 300 dpi
Media Sizes	Letter, Legal, A4, A5, B5, Custom sizes
Connectivity	USB 2.0, Ethernet
Mobile Printing	Apple AirPrint
Operating System Compatibility	Windows, Mac, Linux
Dimensions (W x D x H)	500 mm
Weight	29.6 kg
Print Speed	Up to 36 ppm (Black) / Up to 36 ppm (Color)
