Xerox WorkCentre 6605

General Information
Xerox Internal Use Only Phaser 6600 and WorkCentre 6605
Service Manual
1-73
Wireless
Wireless Adapter is required.
Note: Connection to the Linux machine is not guaranteed. Only for infrastructure connection and
when Linux terminal is connected with Wired LAN connection.
Item Specification
Conectivity Technology Wireless
Compliant Standards IEEE802.11 n/g/b
Band width 2.4GHz
Data Transfer Rate IEEE802.11n mode: 65 Mbps
IEEE802.11g mode: 54, 48, 36, 24, 18, 12, 9, 6 Mbps
IEEE802.11b mode: 11, 5.5, 2, 1 Mbps
Protocol See “Network Protocol” for details
Device Type Wireless Adapter
Security Protocol 64(40-bit key)/128(104-bit key)
WEP,WPA-PSK(TKIP,AES), WPA2-PSK(AES),
WPA-Enterprise(TKIP,AES), WPA2-Enterprise(AES)
(EAP method supports PEAPv0 only)
Wifi Protected Setup (WPS) Push Button Configuration (PBC), Personal Identification Number (PIN)
