Atlas Copco Power Focus 3000 User Manual

Digital I/O and fieldbus items
318 (428) 9836 3123 01
Name
Description
Fieldbus items
Duration
Tensor ST/SL
String
length
Value
Set signal
/ Reset signal
Time
To next tightening
Tracking
Blue LED
Sound (time duration for all)
Illuminator
TLS ST Tag LED
PVT mon
status
LOW / Run
down angle
status
LOW /
PVT
selftap
status
LOW /
Current
status
LOW
Result is below min
limit. There are
three different items
in the setup.
1 bit
0 = Not used
1 = Low
Tightening result /
Start new
tightening or new
Pset selected or
new Job selected
PVT mon
status OK /
Run down
angle status
OK / PVT
selftap
status OK /
Current
status OK
A result is within
limits. There are
three different
variables in the
setup.
1 bit
0 = Not used
1 = OK
Tightening result /
Start new
tightening or new
Pset selected or
new Job selected
Read result
Handshake
ack
Handles read result
1 byte
BF
0 = Not used
1 = Read
2 = Skip
4 = Flush
8 = Result
data in queue
Result is in the
queue or Readresult
Handshake is set in
To PF / No signal
Received
identifier
Indicates identifier
has been received
by PF.
1 bit
0 = Not used
1 = Received
identifier
Received identifier
/ Start new
tightening
X
X
X
X
Rehit
Indicates tool is
rehit
1 bit
0 = Not used
1 = Rehit
Tightening result /
Reset result
X
X
X
X
X
Remaining
batch
Display currently
remaining batch
BF
U16
Batch Counter
Changed / No
signal
Remaining
batch bit 0-
6
Display currently remaining Batch. Batch Counter 1 to 99 can be
displayed. “0” means that there is no remaining batch counter (batch is
completed).
X
