Atlas Copco Power Focus 3000 User Manual

Digital I/O and fieldbus items
9836 3123 01 319 (428)
Name
Description
Fieldbus items
Duration
Tensor ST/SL
String
length
Value
Set signal
/ Reset signal
Time
To next tightening
Tracking
Blue LED
Sound (time duration for all)
Illuminator
TLS ST Tag LED
Result type
Shows what type of
result is, i.e.
tightening result,
loosening result and
so on.
2 – 8 bits
BF
1 to 13 is defined
for the different
result type
Tighten result /
Reset result
Ring button
ack
Ring button pressed
acknowledge.
1 bit
0 = Not used
1 = New Pset
Ring Button
Pressed / Start new
tightening
Rundown
Angle
Show Result
Rundown angle
2 bytes
U16
Tightening result /
Start new tightening
or new Pset
selected or new Job
selected
Running
job ID
Running Job
identification
number.
2 - 8 bits
in the
same byte
BF
0000 0001 = Job
1
0001 0000 = Job
16
Job selected / Job
done
16 bits in
one word
U16
00….0001 = Job
1
00….1000 = Job
8
Running
Job bit 0-8
Shows selected Job. Bit pattern analogue to input Job select bits.
0 = no running Job.
X
Running
Pset ID
Running Pset
identification
number.
2 - 8 bits in
the same
byte
BF
0000 0001 =
Pset 1
0001 0000 =
Pset 16
Pset selected / No
signal. On until new
Pset is selected
16 bits in
one word
U16
00….0001 =
Pset 1
00….1000 =
Pset 8
Running
Pset bit 0-9
Shows selected Pset. Bit pattern analogue to input Pset select bits.
0 = no Pset selected, tool locked.
X
Running
Pset ID 0 is
1
Shows running Pset
and Pset number is
bit field number +1,
i.e. 00 is Pset 1.
2 - 8 bits
in the
same byte
BF
0000 0001=Pset2
0001 0000=Pset
17
Pset selected / No
signal. On until new
Pset is selected
