Atlas Copco Power Focus 3000 User Manual

Parameter list
9836 3123 01 343 (428)
Parameter
number
Parameter name
Description
Default
setup
P113
Final target
Defines the desired final torque value when a torque (tq) P100 Control
strategy is used. The tool shuts off when the final target value is reached.
To maintain accuracy when tightening, final target shouldn't
be lower than specified minimum for the tool in use. Refer to
tool catalogue for necessary data.
9999 Nm
P114
Final tq max
Defines the upper torque limit for OK tightening. The tool shuts off if the
torque value exceeds this value.
0.5 * T102
Tool max
torque
P115
Cycle complete
This parameter indicates the torque level when the tightening cycle is
complete (valid if the tool has shut off prior to reaching this level)..
0.03 * T102
Tool max
torque
P116
Rundown complete
The torque level when the rundown phase is finished. (Only used if P104
Rundown angle or any of the PVT options are selected).
0.2 * T102
Tool max
torque
P118
Measure torque at
Defines at what point the torque is measured.
Torque peak: gives the highest torque value during the tightening.
Angle peak: gives the torque at the highest angle value.
Shut off: measures the torque when the target condition has been fulfilled.
Torque
peak
P119
Loosening limit
Defines the limit for a valid loosening. Adjustable from 0 to T102 Tool max
torque.
0.1 * T102
Tool max
torque
P120
Start final angle
Angle measurement starts when the torque value exceeds this value. P120
Start final angle must be selected equal to or greater than P110 Cycle start.
(If a PVT option is used then it has to be greater than P116 Rundown
complete.)
0.25 * T102
Tool max
torque
P121
Measure angle to
Defines to what point the final angle is measured. The start point is always
P120 Start final angle.
Torque peak: gives the angle at the highest torque value.
Angle peak: gives the highest angle value during the tightening.
Cycle complete: measures the angle at P115 Cycle complete.
Shut off: measures the angle when the target condition has been fulfilled.
Angle peak
P122
Final angle min
This parameter indicates the lower limit for final angle. If the final angle is
below this level the tightening is considered as NOK.
0 deg
P123
Target angle
Indicates the target value for the angle in degrees when angle control, ang
con, is used. When this value is reached the tool is turned off.
0 deg
P124
Final angle max
Defines the upper limit for the tightening angle. If the angle exceeds this level
the tightening is considered as NOK and the tool will shut off.
9999 deg
P125
Rundown angle min
This parameter indicates the min limit value for P104 Rundown angle. If the
angle is smaller than this value at P116 Rundown complete, “low” is indicated
and the tool will shut off.
0 deg
P126
Rundown angle
max
This parameter indicates the max limit value for P104 Rundown angle. If the
angle is larger than this value, “high” is indicated and the tool will shut off.
9999 deg
