Atlas Copco Power Focus 3000 User Manual

Parameter list
344 (428) 9836 3123 01
Parameter
number
Parameter name
Description
Default
setup
P127
Final angle max
mon
Defines the upper limit for the tightening angle. If the angle exceeds this level
the tightening is considered as NOK but the tightening will NOT shut off due
to this.
9999 deg
P128
Rehit angle
Defines the max angle for rehit detection.
Only for MW tool.
0 deg
P130
Soft start speed
Defines the tool speed during the soft start interval.
Allowed interval is between 1 and 30 percent of maximum tool speed.
10%
P131
Step 1 speed
Defines the first step speed.
Speed is adjustable between 1 and 100 percent of max tool speed.
100%
P132
Step 2 speed
Defines the second step speed.
Speed is adjustable between 1 and 40 percent of the tool max speed.
If two stage tightening is used the speed in the second step will increase
according to the P136 Step 2 ramp until it reaches this value. If quick step is
used the tool changes to step 2 speed directly without using a ramp.
40%
P133
Loosening speed
Defines speed during loosening. The value is adjustable between 1 and 100
percent.
100%
P134
Loosening ramp
Defines acceleration during loosening. The value is adjustable between 0 and
100 percent. A low percentage gives fast acceleration.
0%
P135
Step 1 ramp
Defines step 1 acceleration. The value is adjustable between 0 and 100
percent. A low percentage gives fast acceleration (0% is normally used).
0%
P136
Step 2 ramp
Defines step 2 acceleration. A low percentage gives fast acceleration (0-
100%).
20%
P137
Ergo ramp
Defines the acceleration. The value is adjustable between 0 and 100 percent.
Only used if ergo ramp is chosen as the P101 Tightening strategy.
40%
P138
Zoom step speed
Defines the speed used for zoom step strategy. The value is a percentage of
the tool’s max speed. The value is adjustable between 1 and 20 percent.
To set zoom step speed, parameter P105 Zoom step must be active.
10%
P139
Speed unit
Sets speed parameters (P130-P133, P138 and P161) relative to tool max
speed ("Percent") or absolute ("RPM") for current P-set.
Changes between RPM and % due to less accuracy in % can
lead to quantization effects in values for speed parameters.
“Percent”
P141
End time
Defines the time required for the torque level to stay below 115 Cycle
complete before the tightening is aborted (valid if the tool has not shut off
prior to reaching cycle complete).
The value is adjustable between 0.02 and 5.0 seconds.
0.2 s
P142
Soft start time
During this time, from the moment that the tool trigger is pressed, the spindle
rotates very slowly. This gives the operator a chance to fit the socket on the
screw. The value is adjustable between 0.0 and 5.0 seconds.
0.2 s
P143
Tool idle time
Defines the idle time between a completed tightening and the start of the next
tightening. (Used in Multistage).
The value is adjustable between 0 and 32 seconds.
0.0 s
