4-93
Chapter 4. Functions
(1) Specify the groups of the linearization table in the analog output bank.
• BLOCK A2
Item (bank) Display Description Initial value
Linearization table group definition
(ANALOG OUTPUT bank)
MENU > AnalogOutput
Linearization table group
0: No linearization
1 to 2: Groups 1 to 2
3: Group 3 ←Select this
4 to 8: Groups 4 to 8
0
(2) In the DI/DO configuration bank, set the operation type of the DI/DO to be
used as digital input to “DI.”
• DI/DO1
Item (bank) Display Description Initial value
DI/DO group 1 operation
(DI/DO configuration bank)
MENU > DI/DO Config
DI/DO1 Operation type
0: DI ←Select this
1: DO
0
(3) Set the items related to the DI function in the DI bank.
• DI 1
Item (bank) Display Description Initial value
DI group 1 operation
type
(DI bank)
MENU > DI
GROUP1 / Operation
type
0: No function
(Explanation of the settings for 1 to 14 is omitted.)
15: Output linearization table group selection (0/+1)
←Select this
16: Output linearization table group selection (0/+2)
17: Output linearization table group selection (0/+4)
(Explanations on the settings for 18 and later are omitted.)
0
DI group 1 input type
(DI bank)
MENU > DI
GROUP1 / Input type
0: Always OFF
1: Always ON
2 to 10: undefined
11: DI1 ←Select this
12: DI2
13: DI3
14: DI4
15: DI5
16: DI6
17: DI7
1024 to 2047: Standard bits
0
DI group 1 loop
definition
(DI bank)
MENU > DI
GROUP1 / Loop
definition
When the operation type is output linearization table
group selection:
0: No block specification (invalid)
1: Block A2 ←Select this
2: Block B2 (including the motor drive outputs)
3: Block A1
4: Block B1
0
(4) Set the linearization table.
Linearization by specifying breakpoints (p.4-90)(2) Linearization tables
(for a linearization table setting example)
