Azbil C7G User Manual

4-97
Chapter 4. Functions
Item (bank) Display Description Setting value
Output range of block A2
(ANALOG OUTPUT bank)
MENU > AnalogOutput
Block A2 / Output range
0: 4 to 20 mA
1: 0 to 20 mA
0
Output type of block A2
(ANALOG OUTPUT bank)
MENU > AnalogOutput
Block A2 / Output type
0: Fixed at 0 %
1: MV
2 to 3: Reserved
4: PV
5: SP
6: Deviation (PV - SP)
2048 to 3071: Standard
numerical codes
14 - 2 Standard Bit
Codes and Standard
Numerical Codes (p.14-6)
1
Loop definition of block A2
(ANALOG OUTPUT bank)
MENU > AnalogOutput
Block A2 / Loop Definition
1: Loop 1
2: Loop 2
3: Loop 3
4: Loop 4
2
Output scaling low limit of
block A2
(ANALOG OUTPUT bank)
MENU > AnalogOutput
Block A2 / Output scaling
low limit
−32000 to +32000 0.0000
Output scaling high limit of
block A2
(ANALOG OUTPUT bank)
MENU > AnalogOutput
Block A2 / Output scaling
high limit
−32000 to +32000 100.00
