Azbil C7G User Manual

4-122
Chapter 4. Functions

Loop 1
Item (bank) Display Description Initial value
PV assignment
(Input assignment bank)
MENU > InputAssignment
PV assignment
2048 to 3071: Standard
numerical codes
2312
RSP assignment
(Input assignment bank)
MENU > InputAssignment
RSP assignment
2048
Assignment range low limit
(Input assignment bank)
MENU > InputAssignment
Assignment range low limit
−32000 to +32000
A maximum of 5 digits, plus 4
digits after the decimal point,
can be set.
0.0000
Assignment range high limit
(Input assignment bank)
MENU > InputAssignment
Assignment range high limit
1000.0

Loop 2
Item (bank) Display Description Initial value
PV assignment
(Input assignment bank)
MENU > InputAssignment
PV assignment
2048 to 3071: Standard
numerical codes
2313
RSP assignment
(Input assignment bank)
MENU > InputAssignment
RSP assignment
2048
Assignment range low limit
(Input assignment bank)
MENU > InputAssignment
Assignment range low limit
−32000 to +32000
A maximum of 5 digits, plus 4
digits after the decimal point,
can be set.
0.0000
Assignment range high limit
(Input assignment bank)
MENU > InputAssignment
Assignment range high limit
1000.0

Loop 3
Item (bank) Display Description Initial value
PV assignment
(Input assignment bank)
MENU > InputAssignment
PV assignment
2048 to 3071: Standard
numerical codes
2314
RSP assignment
(Input assignment bank)
MENU > InputAssignment
RSP assignment
2048
Assignment range low limit
(Input assignment bank)
MENU > InputAssignment
Assignment range low limit
−32000 to +32000
A maximum of 5 digits, plus 4
digits after the decimal point,
can be set.
0.0000
Assignment range high limit
(Input assignment bank)
MENU > InputAssignment
Assignment range high limit
1000.0

Loop 4
Item (bank) Display Description Initial value
PV assignment
(Input assignment bank)
MENU > InputAssignment
PV assignment
2048 to 3071: Standard
numerical codes
2315
RSP assignment
(Input assignment bank)
MENU > InputAssignment
RSP assignment
2048
Assignment range low limit
(Input assignment bank)
MENU > InputAssignment
Assignment range low limit
−32000 to +32000
A maximum of 5 digits, plus
4 digits after the decimal
point, can be set.
0.0000
Assignment range high limit
(Input assignment bank)
MENU > InputAssignment
Assignment range high limit
1000.0
