5-13
Chapter 5.
Screens


F
or 2 loops
PTN. pattern numbers
SEG. segment numbers


F
or 1 loop
MV bar graph
PTN. pattern numbers
SEG. segment numbers
Specied pattern time and
remaining time
PTN. pattern numbers
SEG. segment numbers
PTN. pattern numbers
SEG. segment numbers
206
208
