Chapter 5. Screens
(7) PV No. buttons
Displays the PV graph color of each loop. Touching this button displays the
1-loop graph screen for the PV No. that was touched.
(8) Change button
Pressing this button displays the 1-loop graph screen for LOOP1.
(9) Home button
Pressing this button displays the Home screen.
Other displays and buttons conform to the Home screen.
Handling Precautions
• This product does not store the graph display data. When the power is turned
off, the display contents are cleared. After the power has been turned on
again, the product starts drawing the graph from the left end.
• When using this product with the 1 loop setting, the multi-loop graph screen
cannot be displayed.
