5-29
Chapter 5. Screens
(9) [ENTER] button
Touching this button writes the input value to the SP of the LSP group and
returns the display to the monitor screen.
(10) Home button
Pressing this button displays the Home screen.
(11) Menu button
Pressing this button displays the parameter bank menu screen.
Handling Precautions
• An input value in the range from the SP low limit to the high limit and the PV
range is valid. If the input value is invalid, the LSP does not change.
• If the version of the MAIN block firmware is earlier than 6.x.x (where x stands
for any number), the input value setting range is fixed at "−32000 to +32000."
• Parameter setting: The setting range of the SP for LSP groups 1 to 8 in the SP
bank is fixed at "−32000 to +32000."
