Chapter 1. Overview

Model C7G with MOTOR Block (Not UL-compliant) Example: C7GA411MC0D00
Main unit I/O Other
DescriptionBase model No.
Comm. Size
Slot
A4
Slot
B4
Slots
A2,
A3,
B2,
B3
Slots
A1,
B1
Option
Add'l
proc.
Add'l
spec.
Special
support
1 2 3 4 5 6 7 8 9 10 11 12 13
C 7 G Multi-loop controller with multifunction display
A Communication (Ethernet, RS-485, USB)
7 digital input/outputs (sink output, source input)
3 Integrating kit included*
1
4 Standard mounting
Slot A4
1 PV1 (full-multi) × 1 AI
Slot B4
0 None (No block)
1 PV2 (full-multi) × 1*
2
AI
Slots A2, A3, B2, B3
M Motor drive output (with MFB input) MOTOR
Slot A1 Slot B1
0 None (No block) (No block)
C Current output (CT and VT inputs, 1 each) × 1 AO-C (No block)
V Voltage pulse output (2 CT inputs) × 1 V-P (No block)
N Current output (CT and VT inputs, 1 each) +
voltage pulse output (2 CT inputs)
AO-C V-P
G Current output (CT and VT inputs, 1 each) +
additional display unit
AO-C HMI2
L Current output (CT and VT inputs, 1 each) +
clock (with battery)
AO-C CLOCK
1 Current output (CT and VT inputs, 1 each) × 4
digital outputs (sink output)
AO-C DO
4 4 digital outputs (sink output) + clock (with
battery)
DO CLOCK
0 None
0 None
D With inspection report
Y With traceability certificate
0 AC power plus CE, KC, and GB compliance
D DC power plus CE, KC, and GB compliance
0 No special support
F Overseas models: switchable between Celsius/Fahrenheit
Do not use these models in Japan.
*1. A rear mounting bracket and a dedicated cable for connecting the display unit are included with the product.
*2. PV2 can be switched for use as RSP1.
