Azbil C7G User Manual

6-3
Chapter 6. Display and Setting Data
Screen Item display Description Notes
Variable
display (4)
SP Displays the SP.
Same as on variable display (1)
Variable display (4) and (5) are applied when
the loop is specified to be displayed for the
AO-C (current output) block in the Basic action
bank.
The relationship between the number of
digits after the decimal point for Resistance in
variable display (5) and the displayed value is
shown below.
2 digits: 0.00 to 999.99 Ω
1 digit: 1000.0 to 9999.9 Ω
0 digits: 10000 to 99999 Ω
Variable display (6) is applied when the loop is
specified to be displayed for the V-P (voltage
pulse) block in the Basic action bank.
MV Displays the MV.
Same as on variable display (1)
CT Displays the CT input value.
Unit: A
Number of decimal places: 1 digit after the decimal point
VT Displays the VT input value.
Unit: V
Number of decimal places: 1 digit after the decimal point
Slot Displays the slot position of an AO-C block, which
has CT and VT input terminals.
Variable
display (5)
SP Displays the SP.
Same as in variable display (1)
MV Displays the MV.
Same as in variable display (1)
Resistance Displays the resistance calculated from the current
of the CT input and the voltage of the VT input.
Unit: Ω
Number of decimal places:
0 to 2 digits after the decimal point (value
changed automatically within 5 digits)
Slot Displays the slot position of an AO-C block, which
has CT and VT input terminals.
Variable
display (6)
SP Displays the SP.
Same as SP display in variable display (1)
MV Displays the MV.
Same as MV display in variable display (1)
CT1 Displays the CT1 input value.
Unit: A
Number of decimal places: 1 digit after the decimal point
CT2 Displays the CT2 input value.
Unit: A
Number of decimal places: 1 digit after the decimal point
Slot Displays the slot position of a V-P block, which has
CT1 and CT2 input terminals.
Variable
display
(MANUAL
MV)
MANUAL MV Displays the MANUAL MV.
The MANUAL MV can be changed by operating the
change digit position and up or down buttons.
Unit: %
Number of decimal places: 1 digit after the decimal point
Switches to this screen when the mode is
switched from AUTO to MANUAL.
(Switches to variable display (1) when the
mode is switched from MANUAL to AUTO.)
This screen is displayed between variable
display (1) and (2).
Variable
display (AT
running)
SP Displays the SP.
In the LSP mode, the LSP group number is
displayed.
In the RSP mode, the RSP is displayed.
Unit: Same as for the PV
Number of decimal places: Same as for PV
Pressing the [x] button at the right side of the
variable display area ends AT.
Switches to this screen when the AT starts.
MV Displays the MV.
Unit: %
Number of decimal places: 1 digit after the decimal point
AT graph The progress status of AT is displayed as a bar graph.
