Chapter 1. Overview
Parameter bank Parameter item
CONTROL
Control action for loops 1 to 4
Differential for ON/OFF control for loops 1 to 4
Heating/cooling control dead zone for loops 1 to 4
PID initial MV for loops 1 to 4
PID initialization for loops 1 to 4
Type of change to MANUAL for loops 1 to 4
Preset MANUAL value for loops 1 to 4
MV increase change limit for loops 1 to 4
MV decrease change limit for loops 1 to 4
MV low limit during AT for loops 1 to 4
MV high limit during AT for loops 1 to 4
SP lag factor for loops 1 to 4
READY MV for loops 1 to 4
Output at READY (heat) for loops 1 to 4
Output at READY (cool) for loops 1 to 4
MV select as PV error for loops 1 to 4
MV value as PV error for loops 1 to 4
Fixed-value output 1 to 8 for loops 1 to 4
SP CONFIG
SP low limit for loops 1 to 4
SP high limit for loops 1 to 4
SP ramp unit for loops 1 to 4
LSP ramp up slope for loops 1 to 4
LSP ramp down slope for loops 1 to 4
RSP tracking for loops 1 to 4
Number of LSP groups for loops 1 to 4
ANALOG OUTPUT
Output range of blocks A2, B2, A1, and B1
Output type of blocks A2, B2, A1, and B1
Loop definition of blocks A2, B2, A1, and B1
Output scaling low limit of blocks A2, B2, A1, and B1
Output scaling high limit of blocks A2, B2, A1, and B1
Linearization table group definition of blocks A2, B2, A1, and
B1
EVENT CONFIG
Operation type for event groups 1 to 16
Loop definition for event groups 1 to 16
Direct/reverse for event groups 1 to 16
Standby for event groups 1 to 16
READY mode operation for event group 1 to 16
DI/DO CONFIG
Operation type of DI/DO 1 to 7
DO CONFIG
Operation type of DO groups 1 to 7 of DI/DO
Operation type of DO groups 1 to 4 of blocks A1 and B1
DI
Operation type of DI groups 1 to 32
Input type of DI groups 1 to 32
Loop definition of DI groups 1 to 32
