13-3
Chapter 13. Specifications

(DI) digital input/(DO) digital output block
Inputs and outputs: 7 max. (switch between DI/DO/TP by setting), common
 Digital input (DI)
Connectable output type: No-voltage contacts or open collector (sink type)
Open terminal voltage: 7 V max.
Terminal current (when shorted):
1 mA (under standard conditions)
Allowable ON contact resistance (no-voltage contact):
500 Ω max. (under standard conditions)
Allowable OFF contact resistance (no-voltage contact):
100 kΩ or more (under standard conditions)
Allowable ON residual voltage for open collector
1 V max. (under standard conditions)
Allowable OFF-state leakage current for open collector:
100 μA max. (under standard conditions)
Input sampling cycle: 10 ms
Minimum detectable pulse width for ON:
20 ms min. (for 10 ms sampling cycle), 50 ms min. (for
50 ms sampling cycle), 100 ms min. (for 100 ms sampling
cycle)
Description of function allocation:
RUN/READY mode selection, AUTO/MANUAL mode
selection, LSP/RSP mode selection, SP group selection,
CDS stop/start, Fixed value output selection, Output
linearization table group selection, Pattern selection, etc.
 Digital output (DO)
Output method: Open collector (sink type)
Load voltage: 4.5 to 28.8 V DC
Maximum load current: 100 mA for each terminal
Overcurrent detection: 130 mA min.
When an overcurrent is detected, the output is turned
OFF, and the status is checked every 5 seconds. If the
status returns to normal, the output returns to normal
automatically.
ON-state residual voltage: 0.5 V max. (under standard conditions)
OFF-state leakage current: 100 μA max. (under standard conditions)
Description of function allocation:
Select from event status or standard bit
