Page #55 background image
3-5
Chapter 3. Wiring
Recommended ferrules (for DI/DO, RS-485, AI, AO-C, V-P)
Model
Product
number
Cross-sectional area
(mm
2
)
Notes
AI 0,25-8 YE 3203037 0.25 (24 AWG) With insulation sleeve
AI 0,34-8-TQ 3203066 0.34 (22 AWG) With insulation sleeve
AI 0,5-8 WH 3200014 0.50 (20 AWG) With insulation sleeve
AI 0,75-8 GY 3200519 0.75 (18 AWG) With insulation sleeve
A1-8 3202517 1.00 (18 AWG) Without insulation sleeve
Used to crimp two JKPEV-S-2Px0.5SQ together.
A1,5-7 3200263 1.50 (16 AWG) Without insulation sleeve
Used to crimp two JKPEV-S-2Px0.75SQ together.
AI-TWIN 2X0,5-8 WH 3200933 0.50 (20 AWG) With insulation sleeve, twin
AI-TWIN 2X0,75-8 GY 3200807 0.75 (18 AWG) With insulation sleeve, twin
Recommended ferrules (for display unit)
Model
Product
number
Cross-sectional area
(mm
2
)
Notes
AI 0,25-6 YE 3203024 0.25 (24 AWG) For display connector, without insulating sleeve
Recommended ferrules (for MOTOR)
Model
Product
number
Cross-sectional area
(mm
2
)
Notes
AI0,75-8 BU 3200027 0.75 (18 AWG) With insulation sleeve
AI1-8 RD 3200030 1.00 (18 AWG) With insulation sleeve
AI1,5-8 RD 3201136 1.50 (16 AWG) With insulation sleeve
AI2,5-10 BU 3202533 2.00 (14 AWG) With insulation sleeve
Handling Precautions
• After instrumentation wiring, check that the ferrules are inserted into the
terminal block correctly.
• When using ferrules, check for improper wire insertion.
• When using the AI-TWIN 2X0,5-8WH or AI-TWIN 2X0,75-8GY, pay special
attention to the terminal crimping orientation so that the insulation
sleeve does not interfere with adjacent terminals when the ferrules are
inserted into the terminal block.
