Brother EV1 - Bobbin Case; Embroidering Attractive Finishes; Removing the Embroidery Frame

Embroidering Preparation
132
3 Slide the embroidery frame into the
holder, making sure to align the
embroidery frame’s with the holder’s
.
a Arrow mark
4 Lower the frame-securing lever to be
level with the frame to secure the
embroidery frame in the embroidery
frame holder.
a Frame-securing lever
 Removing the Embroidery Frame
1
Raise the frame-securing lever.
2 Pull the embroidery frame toward you.
Many factors are involved in achieving a beautiful
embroidery result. Using the appropriate
stabilizer (page 127) and hooping the fabric in
the embroidery frame (page 130) are two
important factors mentioned earlier. There are
several other factors as well.
 Thread
 Bobbin Case
Standard bobbin case (recommended for
sewing and for embroidering with included 60
weight bobbin thread)
a Standard bobbin case (green marking on the
screw)
Standard bobbin case originally installed in the
machine has a green marking on the screw. We
recommend using the included embroidery
bobbin thread with this bobbin case. Do not
adjust the tension screw on this bobbin case with
the green marked screw.
Embroidering Attractive Finishes
CAUTION
• When embroidering large items (especially jackets or
quilts), do not let the fabric hang off of the table.
Otherwise, the embroidery unit cannot move freely and
the embroidery frame may strike the needle, causing the
needle to break and possibly causing injury.
Note
• Recommended to do trial embroidery using
same fabric and threads as project in order to
check the embroidering results.
Upper thread Use embroidery thread intended for use with this
machine.
For most embroidery applications, the upper
thread should be 40-weight rayon or polyester
embroidery thread.
Bobbin thread Use the included 60 weight embroidery bobbin
thread or recommended 60 weight embroidery
bobbin thread.
