Specifications
271
Appendix
8
* Please be aware that some specifications may change without notice.
Chapter 8
Appendix
Specifications
Item Specification
Dimensions of machine 751 mm (W) × 337 mm (D) × 350 mm (H)
(approx. 29-9/16 inches (W) × 13-17/64 inches (D) × 13-25/32 inches (H))
Weight of machine Approx. 19.7 kg (approx. 43 lb)
Dimensions of machine with
embroidery unit attached
Approx. 1090 mm (W) × 671 mm (D) × 350 mm (H)
(approx. 42-29/32 inches (W) × 26-27/64 inches (D) × 13-25/32 inches (H))
Weight of machine with embroidery
unit attached
Approx. 27.0 kg (approx. 59 lb)
Sewing speed 70 to 1050 stitches per minute
Maximum embroidery speed 1050 stitches per minute
Interfaces
Wireless LAN
*1
None, Enhanced Open, WEP, WPA/WPA2-Personal, WPA3-
Personal
• A wireless network cannot be set up with WPA/WPA2/WPA3
Enterprise.
Memory Stitch patterns 1 MB
Embroidery patterns 10 MB
My Design Center 100 MB
Data types
*2
Sewing stitch patterns
*3
.pmz, .pmp, .pmv, .pmx, .pmu
Embroidery patterns
*4
.pes .phc .phx .dst .pen
Data that can be retrieved/
imported when using My
Design Center
• Pattern editing data (.pm9)
• Motif stitch pattern data (.pmf)
• Decorative fill pattern data (.plf)
Image data can be used for the
My Design Center and Picture
Play embroidery function
.jpg, .png, .bmp
• Less than 6 MB and 16 million pixels or less
Number of decorative stitch pattern
combinations
Up to 70
Maximum embroidering area 465 mm (H) × 297 mm (W) (approx.18-1/4 inches (H) × 11-5/8 inches (W))
Types of USB Devices/ Media that
can be used
• USB Flash drive (Type A)
Supported formats: FAT32 and NTFS
Recommended size: 8 to 32 GB
• Some USB media may not be usable with this machine.
Condition of the [Eco Mode] and
[Shutoff Support Mode]
[Eco Mode] Available time OFF, 10 - 120 (minute)
“Start/Stop” button Green flashing
Suspended function Machine light, Screen display
After recovering The machine starts from the
previous operation.
[Shutoff Support Mode] Available time OFF, 1 - 12 (hour)
“Start/Stop” button Green slow flashing
Suspended function All functions
After recovering An error message appears.
You need to turn off and on the
machine to restart.
Compatible image files of the Screen
Saver Image
Format .jpg
File size Max. 2 MB for each image
File dimension 800 × 1280 pixels or less (If the width is more than 800 pixels, the
image imported will be reduced to a width of 800 pixels.)
Number allowed 5 or less
To Next Page
