LCD Screen
22
Touch to change the default machine settings
(language, speaker volume, opening display,
etc.).
a Display sewing settings
b Display general settings
c Display embroidery settings
d Display wireless LAN settings
e The settings on the page containing this key will be
reverted to their defaults.
f An image of the current settings screen can be
saved on USB media. Connect the USB media to
the USB port of the machine. The image file will be
saved in a folder labeled [bPocket].
Sewing Settings
Page 1
a Select whether to use the sewing speed controller
to determine the zigzag width. (page 73)
When a straight stitch is selected, the sewing
speed controller can be used to change the needle
position. (page 81)
b Make adjustments to character or decorative stitch
patterns. (page 105)
c Adjust the presser foot height. Select the height of
the presser foot when the presser foot is raised.
d Adjust the presser foot pressure. The higher the
number, the greater the pressure will be. Set the
pressure at [3] for normal sewing.
e When set to on, the thickness of the fabric is
automatically detected by an internal sensor while
sewing. This enables the fabric to be fed smoothly.
(page 73, page 79)
Page 2
a Select whether [1-01 Straight stitch (Left)] or [1-03
Straight stitch (Middle)] is the utility stitch that is
automatically selected when the machine is turned
on.
b Change the height of the presser foot when sewing
is stopped when the pivot setting is selected.
(page 72)
Settings Screen
• Touch or to display the previous or
next page.
• is a switch for turning on or off a
function. When the switch appears as ,
the function is turned off (cannot be used).
To Next Page
