LINK AGGREGATION COMMANDS
The Link Aggregation commands in the Command Line Interface (CLI) are listed (along with the
appropriate parameters) in the following table.
Command Parameter
create link_aggregation
group_id <value 1-8> {type [lacp | static]}
delete link_aggregation
group_id <value 1-8>
config link_aggregation
group_id <value 1-8> master_port <port 1-28> ports <portlist>
show link_aggregation {group_id <value 1-8> | algorithm}
Each command is listed in detail, as follows:
create link_aggregation
Purpose To create a link aggregation group on the Switch.
Syntax
create link_aggregation group_id <value 1-8> {type [lacp |
static]}
Description
The create link_aggregation command creates a link aggregation
group with a unique identifier.
Parameters
group_id <value 1-8> − Specifies the group ID. The Switch allows up
to 8 link aggregation groups to be configured. The group number
identifies each of the groups.
type – Specify the type of link aggregation used for the group. If the
type is not specified the default type is static.
• lacp – This designates the port group as LACP compliant.
LACP allows dynamic adjustment to the aggregated port
group. LACP compliant ports may be further configured
(see config lacp_ports). LACP compliant must be
connected to LACP compliant devices. The maximum
ports that can be configure in the same LACP are 16.
• static – This designates the aggregated port group as
static. Static port groups can not be changed as easily as
LACP compliant port groups since both linked devices
must be manually configured if the configuration of the
trunked group is changed. If static link aggregation is used,
be sure that both ends of the connection are properly
configured and that all ports have the same speed/duplex
settings. The maximum ports that can be configure in the
same static LAG are 8
Restrictions Only administrator or operator-level users can issue this command.
Example usage:
To create a link aggregation group:
DES-1210-28/ME:5# create link_aggregation group_id 1
Command: create link_aggregation group_id 1
