D-Link DGS-3000

DGS-3000 Series Layer 2 Managed Gigabit Ethernet Switch CLI Reference Guide
177
Restrictions
None.
Example
To show the MEPs and MIPs created on a port:
DGS-3000-26TC:admin#show cfm port 2
Command: show cfm port 2
MAC Address: 00-01-02-03-04-02
MD Name MA Name MEPID Level Direction VID
----------- ----------- ----- ----- --------- ----
op_domain op1 1 2 Inward 1
DGS-3000-26TC:admin#
cfm lock md 16-19
Description
This command is used to start/stop cfm management lock. This command will result in the MEP
sends a LCK PDU to client level MEP.
Format
cfm lock md [<string 22> | md_index <uint 1-4294967295>] ma [<string 22> | ma_index <uint
1-4294967295>] mepid <int 1-8191> remote_mepid <int 1-8191> action [start | stop]
Parameters
md - Specify the maintenance domain name.
<string 22> - Enter the maintenance domain name here. This name can be up to 22
characters long.
md_index - Specify the MD index value used.
<uint 1-4294967295> - Enter the MD index value used here. This value must be between
1 and 4294967295.
ma - Specify the maintenance association name.
<string 22> - Enter the maintenance association name here. This name can be up to 22
characters long.
ma_index - Specify the MA index value used.
<uint 1-4294967295> - Enter the MA index value used here. This value must be between
1 and 4294967295.
mepid - The MEP ID in the MD which sends LCK frame.
<int 1-8191> - Enter the MEP ID value here. This value must be between 1 and 8191.
remote_mepid - The peer MEP is the target of management action.
<int 1-8191> - Enter the remote MEP ID used here. This value must be between 1 and 8191.
action - Specify to start or to stop the management lock function.
start - Specify to start the management lock function.
stop - Specify to stop the management lock function.
