DGS-3000 Series Layer 2 Managed Gigabit Ethernet Switch CLI Reference Guide
180
ma_index - Specify the maintenance association index.
<uint 1-4294967295> - Enter the maintenance association index value here. This value
can be between 1 and 4294967295.
ttl - (Optional) Specify the link trace message TTL value. The default value is 64.
<int 2-255> - Enter the link trace message TTL value here. This value must be between 2 and
255.
pdu_priority - (Optional) The 802.1p priority to be set in the transmitted LTM. If not specified, it
uses the same priority as CCMs sent by the MA.
<int 0-7> - Enter the PDU priority value here. This value must be between 0 and 7.
Restrictions
None.
Example
To transmit an LTM:
DGS-3000-26TC:admin#cfm linktrace 00-01-02-03-04-05 mepname mep1
Command: cfm linktrace 00-01-02-03-04-05 mepname mep1
Transaction ID: 26
Success.
DGS-3000-26TC:admin#
show cfm linktrace 16-22
Description
This command is used to show the link trace responses. The maximum link trace responses a
device can hold is 128.
Format
show cfm linktrace [mepname <string 32> | mepid <int 1-8191> md [<string 22> | md_index
<uint 1-4294967295>] ma [<string 22> | ma_index <uint 1-4294967295>]] {trans_id <uint>}
Parameters
mepname - Specify the MEP name used.
<string 32> - Enter the MEP name used here. This name can be up to 32 characters long.
mepid - Specify the MEP ID used.
<int 1-8191> - Enter the MEP ID used here. This value must be between 1 and 8191.
md - Specify the maintenance domain name.
<string 22> - Enter the maintenance domain name her. This name can be up to 22
characters long.
md_index - Specify the maintenance domain index.
<uint 1-4294967295> - Enter the maintenance domain index value here. This value
must between 1 and 4294967295.
ma - Specify the maintenance association name.
<string 22> - Enter the maintenance association name her. This name can be up to 22
characters long.
ma_index - Specify the maintenance association index.
