DGS-3000 Series Layer 2 Managed Gigabit Ethernet Switch CLI Reference Guide
615
Format
config stp mst_ports <portlist> instance_id <value 0-7> {internalCost [auto | <value 1-
200000000>] | priority <value 0-240>}
Parameters
mst_ports - Specify to be distinguished from the parameters of ports only at CIST level.
<portlist> - Enter a list of ports used for the configuration here.
instance_id - Specify the instance ID used.
<value 0-7> - Enter the instance ID used here. This value must be between 0 and 7.
internalCost - (Optional) Specify the port path cost used in MSTP.
auto - Specify that the internal cost value will be set to auto.
<value 1-200000000> - Enter the internal cost value here. This value must be between 1 and
200000000.
priority - (Optional) Specify the port priority value.
<value 0-240> - Enter the port priority value here. This value must be between 0 and 240.
Restrictions
Only Administrators, Operators and Power-Users can issue this command.
Example
To configure STP MST ports:
DGS-3000-26TC:admin#config stp mst_ports 1 instance_id 0 internalCost auto
Command: config stp mst_ports 1 instance_id 0 internalCost auto
Success.
DGS-3000-26TC:admin#
config stp ports 56-11
Description
This command is used to configure all the parameters of ports, except for Internal Path Cost and
Port Priority.
Format
config stp ports <portlist> {externalCost [auto | <value 1-200000000>] | hellotime <value 1-
2> | migrate [yes | no] | edge [true | false | auto] | p2p [true | false | auto] | state [enable |
disable]| restricted_role [true | false] | restricted_tcn [true | false] | fbpdu [enable | disable]}
Parameters
<portlist> - Enter a list of ports used for the configuration here.
external_cost - (Optional) The path cost between MST regions from the transmitting Bridge to
the CIST Root Bridge. It is only used at CIST level.
auto - Specify that the external cost value will be set to automatic.
<value 1-200000000> - Enter the external cost value here. This value must be between 1 and
