DGS-3000 Series Layer 2 Managed Gigabit Ethernet Switch CLI Reference Guide
674
Chapter 68 QinQ Command List
enable qinq
disable qinq
config qinq inner_tpid <hex 0x1 - 0xffff>
config qinq ports [<portlist> | all] {role [uni | nni] | missdrop [enable | disable] | outer_tpid <hex
0x1 - 0xffff> | add_inner_tag [<hex 0x1 - 0xffff> | disable]}
show qinq
show qinq inner_tpid
show qinq ports {<portlist>}
create vlan_translation ports [<portlist> | all] [add cvid <vidlist> | replace cvid <vlanid 1-4094>]
svid <vlanid 1-4094> {priority <priority 0-7>}
delete vlan_translation ports [<portlist> | all] {cvid <vidlist>}
show vlan_translation {[ports <portlist> | cvid <vidlist>]}
enable qinq 68-1
Description
This command is used to enable QinQ. When QinQ is enabled, all network port roles will be NNI
ports and outer TPID will be set to 0x88A8; all existing static VLANs will run as S-VLAN; all
dynamic learned L2 address will be cleared; all dynamic registered VLAN entries will be cleared;
and GVRP will be disabled.
To run GVRP on the Switch, the administrator should enable GVRP manually. In QinQ mode,
GVRP protocol will employ reserve address 01-80-C2-00-00-0D.
Format
enable qinq
Parameters
None.
Restrictions
Only Administrators, Operators and Power-Users can issue this command.
Example
To enable QinQ:
DGS-3000-26TC:admin#enable qinq
Command: enable qinq
Success.
DGS-3000-26TC:admin#
