DGS-3000 Series Layer 2 Managed Gigabit Ethernet Switch CLI Reference Guide
179
<string 1500> - Enter the pattern used here. This value can be up to 1500 characters long.
pdu_priority - (Optional) The 802.1p priority to be set in the transmitted LBMs. If not specified, it
uses the same priority as CCMs and LTMs sent by the MA.
<int 0-7> - Enter the PDU priority value here. This value must be between 0 and 7.
Restrictions
None.
Example
To transmit a LBM:
DGS-3000-26TC:admin#cfm loopback 32-00-70-89-31-06 mepname mep1
Command: cfm loopback 32-00-70-89-31-06 mepname mep1
Reply from 32-00-70-89-31-06: bytes=0 time=50ms
Reply from 32-00-70-89-31-06: bytes=0 time=50ms
Reply from 32-00-70-89-31-06: bytes=0 time=50ms
Reply from 32-00-70-89-31-06: bytes=0 time=50ms
CFM loopback statistics for 32-00-70-89-31-06:
Packets: Sent=4, Received=4, Lost=0(0% loss).
DGS-3000-26TC:admin#”
cfm linktrace 16-21
Description
This command is used to issue a CFM link track message.
Format
cfm linktrace <macaddr> [mepname <string 32> | mepid <int 1-8191> md [<string 22> |
md_index <uint 1-4294967295>] ma [<string 22> | ma_index <uint 1-4294967295>]] {ttl <int 2-
255> | pdu_priority <int 0-7>}
Parameters
<macaddr> - Enter the destination MAC address.
mepname - Specify the MEP name used.
<string 32> - Enter the MEP name used here. This name can be up to 32 characters long.
mepid - Specify the MEP ID used.
<int 1-8191> - Enter the MEP ID used here. This value must be between 1 and 8191.
md - Specify the maintenance domain name.
<string 22> - Enter the maintenance domain name her. This name can be up to 22
characters long.
md_index - Specify the maintenance domain index.
<uint 1-4294967295> - Enter the maintenance domain index value here. This value
can be between 1 and 4294967295.
ma - Specify the maintenance association name.
<string 22> - Enter the maintenance association name her. This name can be up to 22
characters long.
